Simrad SS75M 12 Degree Tilt
Model: 000-13909-001- CHIRP transducers enable bottom detection with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures.
- Calculates how deep the water is, so that you can avoid running aground, whilst also incorporating a temperature sensor for accurate water temperature readings.
- CHIRP range is 80kHz-130kHz for good target detail in shallow water and excellent bottom tracking in deep water.
- Provides extremely accurate data.
- The 12° tilt is ideal for boats with a 8° to 15° hull deadrise.
- The low profile housing minimizes drag with just 5mm extending outside of the hull.
- Easily connect to NSSevo3
The SS75M is a bronze, thru-hull, tilted, medium-frequency (80-130kHz), depth and temperature transducer. The ceramic element is tilted for built-in deadrise compensation, giving excellent echo returns for more accurate depth readings.
SpecificationsFrequency | Medium CHIRP (80-130kHz) |
Power rating | 600 watts |
Speed sensor | No |
Temperature sensor | Yes |
Mounting style | Stainless Steel Thru-hull |
Elements | 1 |
Beamwidth @ -3db | 24° to 16° |
Cable length | 10 meter |
