Description
Finally a battery that is high quality AND affordable! Superior Plates with an expected life span of 10 to 12 years in float service applications.
| Nominal Voltage | 20Hr Capacity | CCA |
MCA |
RC (min) |
Energy (kWH) |
Terminal Posts | Dimensions | Weight |
Charging Current* |
Charging Voltage |
Float Voltage |
| 12V | 135AH |
800A |
1000A |
265 |
1.8 |
SAE + 5/16" STUD |
13"w x 6.8"d x 8.4"h/9.2th** | 74lb |
10A-35A |
14.6V-14.9V |
13.5V-13.8V |
|
25A @ 1.75/Cell 265Min |
|
|
75A @ 1.75/Cell 75Min |
Short Circuit Current: 2500A
Internal Resistance: 3.2mOhms
Recommended Charging Options:
- AC Chargers: Any Quality Brand AGM- Smart & Microprocessor controlled- charger with the recommended specs above can be used.
- Vehicle Alternator: 14V-15V.
- RV Converter: 14V-15V.
- Solar Panel: 175W-450W.
- Wind Turbine: 175W-450W.
- Charge Controller: 15A-UP
* Warning: Do not use a charger with smaller amperage than the recommended Charging Current shown above. Maintainers should ONLY be used to maintain a fully charged battery but NEVER as a charger.
**Total Height including terminal post.
Operating Temperature Range:
- Discharge: -4~140F
- Charge: 32~120F
- Storage: -4~140F
Temperature Compensation:
- Cycle use: -30mV/C
- Standby use: -20mV/C
